Mounting Base:
Metal base with shock-proof rubber gasket
Characteristics:
Strong self-priming ability, Can quickly exhaust the air in the pipeline; Low power consumption and high efficiency motor; Stable outlet pressure; Low noise, Low vibration
Applications:
Suitable for areas with no pipe pressure and low pipe pressure in mountainous areas; Suitable for reverse osmosis pure water machine, spray device, water treatment equipment, foundry measurement and sanitation, environmental protection, printing industry
| Application of Machine | Business Devices, Home Devices |
|---|---|
| Motor Type | RO Pumps |
| Certifications | CE, CSA, ISO 9001:2008 |
| Minimum Order Quantity | 200 PCs |
| Packaging & Delivery | Carton + Foam Box |
| Payment Method | LC, TT | Wire, West Union |
| Model | Voltage | Ports | Inlet Pressure | Work Pressure | Water Flow @70PSI | Work Current | Rated Current | Self Priming | Dimension | Weight |
|---|---|---|---|---|---|---|---|---|---|---|
| DJ-310-50 | 24 VDC | 3/8″ NPT | 0 ~ 70PSI | > 70 PSI | ≧ 0.6 LPM | ≦ 1.3 A | 1.4 A | 2 M | 202 x 101 x 100 (MM) | 2.1 KGs |
| DJ-310-75 | 24 VDC | 3/8″ NPT | 0 ~ 70PSI | > 70 PSI | ≧ 0.8 LPM | ≦ 1.4 A | 1.5 A | 2 M | 202 x 101 x 100 (MM) | 2.1 KGs |
| DJ-310-100 | 24 VDC | 3/8″ NPT | 0 ~ 70PSI | > 70 PSI | ≧ 0.9 LPM | ≦ 1.6 A | 1.7 A | 2 M | 202 x 101 x 100 (MM) | 2.2 KGs |
